MT2R50K Pneumatic Transfer Printing Press
Double Bottom Mold | 50×60 cm | Steam Function | 4 Bar Operating Pressure
Technical Specifications & Operating Principle
MT2R50K pneumatic transfer printing press features a self-contained boiler and double bottom mold design. Bottom molds include steam spray and serpentine heating. The upper mold is aluminum with resistance heating (4 kW). Digital thermostat ensures homogeneous heat distribution. Safety frame, PTFE non-flammable fabric cover, and European silicone bottom mold are standard.
🖨️ Press & Mold Features
♨️ Steam Boiler Features
Technical Parameter Table
| Parameter | Value |
|---|---|
| Printing Area | 50×60 cm |
| Upper Mold Heater Power | 4 kW |
| Boiler Material | Pressure vessel steel |
| Steam Capacity | 27 kg/h |
| Operating Steam Pressure | 4 bar |
| Boiler Resistance Power | 2×10 kW (20 kW) |
| Condensate Tank | 35 L Stainless |
| Ready Time | Approx. 25 minutes |
| Operating Voltage | 380V / Industrial type |
Important Notice
Use only clean, scale and sediment-free water. Our SYC automatic water softener features a self-cleaning timer function to ensure high efficiency and long service life of the steam boiler and connected equipment. Request the SYC model from your sales representative.
Frequently Asked Questions
What does the steam function provide on MT2R50K?
Steam eliminates fabric shine and ensures adhesion of stones with different heights.
What is the upper mold cover material?
PTFE non-flammable fabric; bottom mold uses European silicone.
What material is the boiler made of?
Pressure vessel steel suitable for pressurized container construction.
